SD Series

Wattage :

15W~1000W

Features :
  • 2:1 wide input range (4:1 for SD-500/1000)
  • 1.5~2KVAC isolation by models
  • 1U low profile (41mm) for SD-1000
  • 12V/0.25A auxiliary output for SD-500/1000
  • Built-in remote ON/OFF control and remote sense for SD-500/1000
Model


SD-15 / SD-25 / SD-50 / SD-100 / SD-150 / SD-200 / SD-350 / SD-500 / SD-1000


RSD Series

Wattage :

30W~300W

Features :
  • Compliance with EN50155 and EN45545-2 railway standard
  • 2:1 or 4:1 wide input range
  • Isolation: 4000VDC
  • 1U low profile
  • Half encapsulated
Model


RSD-30 / RSD-60 / RSD-100 / RSD-150 / RSD-200 / RSD-300


DDR Series

Wattage :

15~240

Features :
  • 4:1 wide input range(DDR-15~60)
  • 2:1 input range(DDR-120~240)
  • Fanless design, cooling by free air convection
  • High efficiency up to 92.5%
  • Protections: short circuit / overload / over voltage / input reverse polarity / input under voltage
  • LED power indicator
  • Suitable for DIN rail types: TS-35/7.5 or TS-35/15
  • 4KVdc I/O isolation (reinforced isolation)
  • Ultra slim dimensions
  • 3 years warranty
Model


DDR-15 / DDR-30 / DDR-60 / DDR-120 / DDR-240


DDRH Series

Wattage :

60W

Features :
  • 150~1500Vdc 10:1 ultra-wide input range
  • Potted with silicone gel, provides dust and moisture protection and free air convection cooling capability
  • -30～+80℃ ultra-wide temperature range ( >+55℃ de-rating)
  • Built-in DC OK relay contact
  • Protections: short circuit / overload / over voltage / over temperature / DC input under voltage / DC input reverse polarity
  • Adjustable output voltage (100~120%)
Model


DDRH-60


PSD Series

Wattage :

5W~45W

Features :
  • 2:1 wide input range
  • 1.5~2KVAC isolation by models
Model


PSD-15 / PSD-30 / PSD-45


Medical – SIP Package

Wattage :

1W~2W

Features :
  • SIP7 package with international standard pinout
  • Operating temperature range -40~ +90°C
  • Medical safety approved (1xMOPP/2xMOOP) according to ANSI AAMI ES60601-1
  • Low patient leakage current <2 μA
  • Protection: Short circuit(3 second max.)
  • 3 years warranty
Model


MDS01 / MDD01 / MDS02 / MDD02


Medical- 2″ x 1″ Package

Wattage :

15W~20W

Features :
  • 2″ x 1″ package with international standard pinout
  • Operating temperature range -40~ +90°C
  • Medical safety approved (2xMOPP according to ANSI AAMI ES60601-1)
  • Low patient leakage current <5 μA
  • 3 years warranty
Model


MDS15 / MDS20


SMD Package

Wattage :

1W~2W

Features :
  • SMD type
  • Single and dual output models
Model

Single：


SBTN01 / SFTN01 / SFTN02


Dual：


DETN01 / DETN02


SIP Package

Wattage :

1W~9W

Features :
  • Regulated and unregulated models
  • ±10% or 2:1 wide input range
  • On board module type, assemble on the main PCB of the system
Model

Regulated ：


SPR01 / SPA01 / SPA02 / SPB03 / SPB05 / DPAN02 / DPBW03 / SPBW03 / SPBW06 / DPBW06 / SPAN02 / SPB09 / DPB09 / SPRN01 / DPRN01


Unregulated ：


SMU01 / SMU02 / SPU02 / SPU03 / SPU01 / DPU01


DIP Package

Wattage :

0.5W~3W

Features :
  • Regulated and unregulated models
  • ±10% input range
  • On board module type, assemble on the main PCB of the system
Model

Regulated ：


SRS / SLC03 / DLC03


Unregulated ：


SUS01 / SMA01


DIP – 1.25″ x 0.8″ Footprint

Wattage :

3W~20W

Features :
  • DIP24 package
  • 2:1 (standard), 4:1 (option) wide input
  • 1~1.5KVDC (standard), 3KVDC (option) isolation
  • Single and dual output models
Model

Single：


SCW03 / SCW05 / SCW08 / SCW12 / SCWN03 / SCW20 / SCWN06 / RSDW08 / RSDW10 / RSDW20


Dual：


DCW03 / DCW05 / DCW08 / DCW12 / DCWN03 / DCWN06 / RDDW08 / RDDW10 / RDDW20


DIP – 1″ x 1″ Footprint

Wattage :

15W~30W

Features :
  • DIP package
  • 1.5KVDC isolation
  • Single output models
  • Remote ON/OFF control, remote sense, trimming output ±10% by models
Model

Single：


SKM10 / SKMW06 / SKM10 / SKM15 / SKMW20 / SKMW30


Dual：


DKMW06 / DKM10 / DKMW20 / DKMW30


DIP – 2″ x 1″ Footprint

Wattage :

5W~50W

Features :
  • DIP package
  • 2:1 (standard), 4:1 (option) wide input
  • 1~1.5KVDC (standard), 3KVDC (option) isolation
  • Single and dual output models
  • Remote ON/OFF control, remote sense, trimming output ±10% by models
Model

Single：


SLW05 / SKE10 / SKA15 / SKA20 / SKM30 / SKM50


Dual：


DLW05 / DKE10 / DKA15


DIP – 2″ x 2″ Footprint

Wattage :

15W~60W

Features :
  • DIP package
  • 2:1 (standard), 4:1 (option) wide input
  • 1~1.5KVDC isolation
  • Single, dual and triple output models
Model

Single：


SKE15 / SDM30 / SKA40 / SKA60


Dual：


DKE15 / DKA30


Triple：


TKA30


Half-brick

Wattage :

75W~150W

Features :
  • Half-brick size (2.28” x 2.4” x 0.5”)
  • DIP package
  • 2:1 wide input range, 1.5KVDC isolation
  • Built-in remote ON/OFF and remote sense
  • 2.5V / 3.3V / 15V output available
  • Optional heat sink available
Model


MHB75 / MHB100 / MHB150


NID Series

Wattage :

30W~100W

Features :
  • Non-isolated
  • 3:1 wide input range
  • High efficiency up to 97%
  • Built-in remote ON/OFF control
  • Economical open frame design
Model


NID30 / NID60


NID35 / NID65 / NID100


NSD Series

Wattage :

5W~15W

Features :
  • 4:1 wide input range
  • 1~1.5KVDC isolation by models
  • Built-in remote ON/OFF control
  • Low cost, high reliability
Model

Single：


NSD05-S / NSD10-S / NSD15-S


Dual：


NSD10-D / NSD15-D
